Ducting Size Guide
Kair Ducting Adaptor Rectangular to Round
Found it cheaper? we will match or beat that price for you wherever possible. See Details
You may return an item within 60 days for a full refund. Returns Details | Delivery Details
Rated Excellent by our customers, See Reviews
Need help or have a query? You can fill in our Contact Form or call us on 020 8463 9696
KAIR OFFSET ROUND TO RECTANGULAR OFFSET ADAPTER/CONNECTOR
- Built to last out of Polystyrene/Polypropylene Material.
- Max / min temperature: +60c / -15c.
- Easy to install and durable, just push-fit duct and fittings together.
- For permanent fixings, seal joints with silicone sealant or tape.
- Suitable to use in compliance with Part F Building Regulations.
- Airflow performance independently tested by BSRIA or BRE.
- Suitable to use in compliance with Part F Building Regulations.
Perfectly suited for ducting your Bathroom, Toilet, or Kitchen extractor fan, hydroponics, in-line extract Fans, tumble dryer, or a cooker hood.
This ducting outlet can be used as a part of a long ductwork run for a variety of purposes including whole-house ventilation, passive stack vent, air conditioning, HVAC, and Heat Recovery Systems.
| Model | DUCVKC253F |
|---|---|
| QS code | QS38893 |
| Barcode | 5060272541064 |
| Product type | Adaptor |
| Product group | Plastic Ducting |
| Flat system (mm) | 110x54 |
| Round system (mm) | 100 |
| Width (mm) | 114 |
| Weight (kg) | 0.093 |
| Height (mm) | 107 |
| Length (mm) | 120 |
| Socket size (mm) | 100 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polystyrene |
| Pressure loss pa 15 ls | 3.7 |
| Pressure loss pa 30ls | 14.6 |
| Pressure loss pa 60 ls | 58 |
| Packaged height (mm) | 102 |
| Packaged length (mm) | 120 |
| Packaged width (mm) | 113 |
| Packaged weight (kg) | 0.093 |
| Model | DUCVKC5615 |
|---|---|
| QS code | QS4113 |
| Barcode | 5060272542467 |
| Product type | Adaptor |
| Product group | Plastic Ducting |
| Flat system (mm) | 204x60 |
| Round system (mm) | 100 |
| Width (mm) | 203 |
| Weight (kg) | 0.15 |
| Height (mm) | 102 |
| Length (mm) | 148 |
| Socket size (mm) | 203 |
| Spigot szie (mm) | 99 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polystyrene |
| Pressure loss pa 15 ls | 6.7 |
| Pressure loss pa 30ls | 21.3 |
| Pressure loss pa 60 ls | 84.7 |
| Packaged height (mm) | 100 |
| Packaged length (mm) | 150 |
| Packaged width (mm) | 203 |
| Packaged weight (kg) | 0.151 |
| Model | DUCVKC5613 |
|---|---|
| QS code | QS309 |
| Barcode | 5060272542450 |
| Product type | Adaptor |
| Product group | Plastic Ducting |
| Flat system (mm) | 204x60 |
| Round system (mm) | 125 |
| Width (mm) | 209 |
| Weight (kg) | 0.187 |
| Height (mm) | 135 |
| Length (mm) | 155 |
| Socket size (mm) | 205 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polystyrene |
| Pressure loss pa 15 ls | 0.96 |
| Pressure loss pa 30ls | 3.84 |
| Pressure loss pa 60 ls | 15.41 |
| Packaged height (mm) | 155 |
| Packaged length (mm) | 210 |
| Packaged width (mm) | 135 |
| Packaged weight (kg) | 0.179 |
| Model | DUCVKC613 |
|---|---|
| QS code | QS346 |
| Barcode | 5060272541774 |
| Product type | Adaptor |
| Product group | Plastic Ducting |
| Flat system (mm) | 150x70 |
| Round system (mm) | 125 |
| Width (mm) | 155 |
| Weight (kg) | 0.112 |
| Height (mm) | 125 |
| Length (mm) | 156 |
| Socket size (mm) | 125 |
| Temp max | 60 |
| Temp min | -15 |
| Pressure loss pa 15 ls | 0.62 |
| Pressure loss pa 30ls | 2.51 |
| Pressure loss pa 60 ls | 10.1 |
| Diameter inner mm | 125 |
| Diameter outer mm | 130 |
| Packaged height (mm) | 127 |
| Packaged length (mm) | 155 |
| Packaged width (mm) | 155 |
| Packaged weight (kg) | 0.114 |
| Model | DUCVKC708 |
|---|---|
| QS code | QS414 |
| Barcode | 5060272543396 |
| Product type | Adaptor |
| Product group | Plastic Ducting |
| Flat system (mm) | 234x29 |
| Round system (mm) | 100 |
| Width (mm) | 239 |
| Weight (kg) | 0.21 |
| Height (mm) | 105 |
| Length (mm) | 175 |
| Socket size (mm) | 233 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polystyrene |
| Pressure loss pa 15 ls | 4.56 |
| Pressure loss pa 30ls | 16.11 |
| Pressure loss pa 60 ls | 56.9 |
| Packaged height (mm) | 105 |
| Packaged length (mm) | 175 |
| Packaged width (mm) | 204 |
| Packaged weight (kg) | 0.206 |
| Model | DUCVKC650 |
|---|---|
| QS code | QS366 |
| Barcode | 5060272542146 |
| Product type | Adaptor |
| Product group | Plastic Ducting |
| Flat system (mm) | 180x90 |
| Round system (mm) | 150 |
| Width (mm) | 185 |
| Weight (kg) | 0.244 |
| Height (mm) | 157 |
| Length (mm) | 180 |
| Socket size (mm) | 180 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polystyrene |
| Pressure loss pa 15 ls | 0.21 |
| Pressure loss pa 30ls | 0.85 |
| Pressure loss pa 60 ls | 3.52 |
| Packaged height (mm) | 152 |
| Packaged length (mm) | 180 |
| Packaged width (mm) | 152 |
| Packaged weight (kg) | 0.221 |
| Model | DOM970 |
|---|---|
| QS code | QS3077 |
| Barcode | 5014662010517 |
| Product type | Adaptor |
| Product group | Plastic Ducting |
| Flat system (mm) | 220x90 |
| Round system (mm) | 150 |
| Width (mm) | 225 |
| Height (mm) | 160 |
| Length (mm) | 203 |
| Spigot szie (mm) | 220x90 |
| Diameter inner mm | 155 |
| Diameter outer mm | 160 |
| Packaged height (mm) | 150 |
| Packaged length (mm) | 200 |
| Packaged width (mm) | 225 |
| Packaged weight (kg) | 0.29 |
