KAIR LOUVRED GRILLE VENT COVER ROUND SPIGOT
Plastic air outlet/air inlet round grille with fixed louvres.
- Wipe-clean durable design for indoor or outdoor use.
- Suitable to use in compliance with Part F Building Regulations.
- Airflow performance independently tested by BSRIA or BRE.
- Built to last out of high-quality Polystyrene/Polypropylene plastic material.
- Easy to install and durable, just push-fit duct and fittings together.
- For permanent fixings, seal joints with silicone sealant or tape.
- Max / Min Temperature: +60c / -15c.
Perfectly suited for ducting your bathroom or kitchen extractor fan, hydroponics, in-line extract fans, tumble dryer, or a cooker hood.
This item can be used as a part of a long ductwork run for a variety of purposes including whole-house ventilation, passive stack vent, positive input ventilation, air conditioning, HVAC, and Heat Recovery systems.
Kair plastic rigid ducting is perfect for DIY and Trade use and provides superior airflow performance and durability versus flexible duct.
| Model | DUCVKC275-BK |
|---|---|
| QS code | QS53928 |
| Product type | Grille - Louvre |
| Product group | Plastic Ducting |
| Round system (mm) | 150 |
| Model | DUCVKC268-BK |
|---|---|
| QS code | QS52262 |
| Round system (mm) | 125 |
| Model | DUCVKC244 |
|---|---|
| QS code | QS197 |
| Barcode | 5060272540944 |
| Product type | Grille - Louvre |
| Product group | Plastic Ducting |
| Round system (mm) | 100 |
| Width (mm) | 40 |
| Weight (kg) | 0.101 |
| Height (mm) | 155 |
| Length (mm) | 155 |
| Spigot szie (mm) | 33 x 96 x 96 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polypropylene |
| Pressure loss pa 15 ls | 6 |
| Pressure loss pa 30ls | 19.8 |
| Pressure loss pa 60 ls | 79.1 |
| Packaged height (mm) | 155 |
| Packaged length (mm) | 155 |
| Packaged width (mm) | 40 |
| Packaged weight (kg) | 0.101 |
| Model | DUCVKC244-BK |
|---|---|
| QS code | QS46702 |
| Barcode | 5060272547356 |
| Product type | Grille - Louvre |
| Product group | Plastic Ducting |
| Round system (mm) | 100 |
| Width (mm) | 40 |
| Weight (kg) | 0.101 |
| Height (mm) | 155 |
| Length (mm) | 155 |
| Spigot szie (mm) | 33 x 96 x 96 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polypropylene |
| Packaged height (mm) | 155 |
| Packaged length (mm) | 155 |
| Packaged width (mm) | 40 |
| Packaged weight (kg) | 0.101 |
| Model | DUCVKC244-TC |
|---|---|
| QS code | QS4486 |
| Barcode | 5060272540982 |
| Product type | Grille - Louvre |
| Product group | Plastic Ducting |
| Round system (mm) | 100 |
| Width (mm) | 40 |
| Weight (kg) | 0.101 |
| Height (mm) | 155 |
| Length (mm) | 155 |
| Spigot szie (mm) | 36 x 96 x 96 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polypropylene |
| Pressure loss pa 15 ls | 6 |
| Pressure loss pa 30ls | 19.8 |
| Pressure loss pa 60 ls | 79.1 |
| Packaged height (mm) | 155 |
| Packaged length (mm) | 155 |
| Packaged width (mm) | 40 |
| Packaged weight (kg) | 0.101 |
| Model | DUCVKC244-BR |
|---|---|
| QS code | QS4445 |
| Barcode | 5060272540968 |
| Product type | Grille - Louvre |
| Product group | Plastic Ducting |
| Round system (mm) | 100 |
| Width (mm) | 42 |
| Weight (kg) | 0.099 |
| Height (mm) | 155 |
| Length (mm) | 155 |
| Spigot szie (mm) | 35 x 96 x 96 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polypropylene |
| Pressure loss pa 15 ls | 6 |
| Pressure loss pa 30ls | 19.8 |
| Pressure loss pa 60 ls | 79.1 |
| Packaged height (mm) | 155 |
| Packaged length (mm) | 155 |
| Packaged width (mm) | 40 |
| Packaged weight (kg) | 0.099 |
| Model | DUCVKC244-BG |
|---|---|
| QS code | QS4467 |
| Barcode | 5060272540951 |
| Product type | Grille - Louvre |
| Product group | Plastic Ducting |
| Round system (mm) | 100 |
| Width (mm) | 40 |
| Weight (kg) | 0.099 |
| Height (mm) | 155 |
| Length (mm) | 155 |
| Spigot szie (mm) | 34 x 96 x 96 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polypropylene |
| Pressure loss pa 15 ls | 6 |
| Pressure loss pa 30ls | 19.8 |
| Pressure loss pa 60 ls | 79.1 |
| Packaged height (mm) | 155 |
| Packaged length (mm) | 155 |
| Packaged width (mm) | 40 |
| Packaged weight (kg) | 0.099 |
| Model | DUCVKC268 |
|---|---|
| QS code | QS223 |
| Barcode | 5060272541439 |
| Product type | Grille - Louvre |
| Product group | Plastic Ducting |
| Round system (mm) | 125 |
| Width (mm) | 44 |
| Weight (kg) | 0.097 |
| Height (mm) | 155 |
| Length (mm) | 155 |
| Spigot szie (mm) | 28 x 120 x 120 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polypropylene |
| Pressure loss pa 15 ls | 4.6 |
| Pressure loss pa 30ls | 18.37 |
| Pressure loss pa 60 ls | 73.41 |
| Packaged height (mm) | 155 |
| Packaged length (mm) | 155 |
| Packaged width (mm) | 44 |
| Packaged weight (kg) | 0.097 |
| Model | DUCVKC268-BG |
|---|---|
| QS code | QS4469 |
| Barcode | 5060272541446 |
| Product type | Grille - Louvre |
| Product group | Plastic Ducting |
| Round system (mm) | 125 |
| Width (mm) | 45 |
| Weight (kg) | 0.098 |
| Height (mm) | 155 |
| Length (mm) | 155 |
| Spigot szie (mm) | 29 x 120 x 120 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polypropylene |
| Pressure loss pa 15 ls | 4.6 |
| Pressure loss pa 30ls | 18.37 |
| Pressure loss pa 60 ls | 73.41 |
| Packaged height (mm) | 155 |
| Packaged length (mm) | 155 |
| Packaged width (mm) | 45 |
| Packaged weight (kg) | 0.098 |
| Model | DUCVKC268-BR |
|---|---|
| QS code | QS4448 |
| Barcode | 5060272541453 |
| Product type | Grille - Louvre |
| Product group | Plastic Ducting |
| Round system (mm) | 125 |
| Width (mm) | 45 |
| Weight (kg) | 0.079 |
| Height (mm) | 155 |
| Length (mm) | 155 |
| Spigot szie (mm) | 30 x 120 x 120 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polypropylene |
| Pressure loss pa 15 ls | 4.6 |
| Pressure loss pa 30ls | 18.37 |
| Pressure loss pa 60 ls | 73.41 |
| Packaged height (mm) | 155 |
| Packaged length (mm) | 155 |
| Packaged width (mm) | 45 |
| Packaged weight (kg) | 0.079 |
| Model | DUCVKC268-TC |
|---|---|
| QS code | QS4488 |
| Barcode | 5060272541477 |
| Product type | Grille - Louvre |
| Product group | Plastic Ducting |
| Round system (mm) | 125 |
| Width (mm) | 45 |
| Weight (kg) | 0.097 |
| Height (mm) | 155 |
| Length (mm) | 155 |
| Spigot szie (mm) | 31 x 120 x 120 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polypropylene |
| Pressure loss pa 15 ls | 4.6 |
| Pressure loss pa 30ls | 18.37 |
| Pressure loss pa 60 ls | 73.41 |
| Packaged height (mm) | 155 |
| Packaged length (mm) | 155 |
| Packaged width (mm) | 45 |
| Packaged weight (kg) | 0.097 |
| Model | DUCVKC275 |
|---|---|
| QS code | QS232 |
| Barcode | 5060272541941 |
| Product type | Grille - Louvre |
| Product group | Plastic Ducting |
| Round system (mm) | 150 |
| Width (mm) | 185 |
| Weight (kg) | 0.169 |
| Height (mm) | 185 |
| Length (mm) | 55 |
| Spigot szie (mm) | 36 x 146 x 146 |
| Temp max | 60 |
| Temp min | -15 |
| Free area | 11440 |
| Material | Polypropylene |
| Pressure loss pa 15 ls | 0.73 |
| Pressure loss pa 30ls | 3 |
| Pressure loss pa 60 ls | 12.33 |
| Packaged height (mm) | 85 |
| Packaged length (mm) | 55 |
| Packaged width (mm) | 85 |
| Packaged weight (kg) | 0.17 |
| Model | DUCVKC275-BR |
|---|---|
| QS code | QS4433 |
| Barcode | 5060272541965 |
| Product type | Grille - Louvre |
| Product group | Plastic Ducting |
| Round system (mm) | 150 |
| Width (mm) | 185 |
| Weight (kg) | 0.169 |
| Height (mm) | 185 |
| Length (mm) | 55 |
| Spigot szie (mm) | 38 x 146 x 146 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polypropylene |
| Pressure loss pa 15 ls | 0.73 |
| Pressure loss pa 30ls | 3 |
| Pressure loss pa 60 ls | 12.33 |
| Packaged height (mm) | 85 |
| Packaged length (mm) | 55 |
| Packaged width (mm) | 85 |
| Packaged weight (kg) | 0.17 |
| Model | DUCVKC275-TC |
|---|---|
| QS code | QS4490 |
| Barcode | 5060272541989 |
| Product type | Grille - Louvre |
| Product group | Plastic Ducting |
| Round system (mm) | 150 |
| Width (mm) | 185 |
| Weight (kg) | 0.169 |
| Height (mm) | 185 |
| Length (mm) | 55 |
| Spigot szie (mm) | 39 x 146 x 146 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polypropylene |
| Pressure loss pa 15 ls | 0.73 |
| Pressure loss pa 30ls | 3 |
| Pressure loss pa 60 ls | 12.33 |
| Packaged height (mm) | 85 |
| Packaged length (mm) | 55 |
| Packaged width (mm) | 85 |
| Packaged weight (kg) | 0.17 |
| Model | DUCVKC275-BG |
|---|---|
| QS code | QS4471 |
| Barcode | 5060272541958 |
| Product type | Grille - Louvre |
| Product group | Plastic Ducting |
| Round system (mm) | 150 |
| Width (mm) | 185 |
| Weight (kg) | 0.169 |
| Height (mm) | 185 |
| Length (mm) | 55 |
| Spigot szie (mm) | 37 x 146 x 146 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polypropylene |
| Pressure loss pa 15 ls | 0.73 |
| Pressure loss pa 30ls | 3 |
| Pressure loss pa 60 ls | 12.33 |
| Packaged height (mm) | 85 |
| Packaged length (mm) | 55 |
| Packaged width (mm) | 85 |
| Packaged weight (kg) | 0.168 |
17 reviews for Kair Louvred Grille with Round Rear Spigot
You must be logged in to post a review.
Read our full delivery information
Free Delivery Over £100
For items in stock. Excludes timed and non UK Mainland deliveries.
Cut off time 12:00 (noon)
Orders placed after midday will be shipped the following working day.
Free Delivery Over £100
For items in stock. Excludes timed and non UK Mainland deliveries.
Cut off time 12:00 (noon)
Orders placed after midday will be shipped the following working day.
DUCVKC244 Kair System 100mm Round - Louvred Grille Vent - Technical Data Sheet
DUCVKC268 Kair System 125mm Round - Louvred Grille Vent - Technical Data Sheet
DUCVKC275 Kair System 150mm Round - Louvred Grille Vent - Technical Data Sheet
Questions and answers of the customers
-
Hi there, I have this grill fitted in two places on my house and wish to change them for Cowled Grille With Damper - Round Spigot - Black.
Are the back plate the same?
This would save a lot of hassle if I could just pop the grill out and replace it with the cowl with damper, without disturbing the inner pipe etc.
Many thanks in advance.
Steve
-
QHi there, I have this grill fitted in two places on my house and wish to change them for Cowled Grille With Damper - Round Spigot - Black. Are the back plate the same? This would save a lot of hassle if I could just pop the grill out and replace it with the cowl with damper, without disturbing the inner pipe etc. Many thanks in advance. Steveanswer nowA Hi Stephen. Yes, if you go for DOM4902BK, then that will have the same sized 100mm spigot on the rear of it.Kind regards, Marc
Good Afternoon,
Please could you tell me how to separate the two parts of this air vent so that I can install it. I have tried but I dont want to break it.
Thank you
-
QGood Afternoon, Please could you tell me how to separate the two parts of this air vent so that I can install it. I have tried but I dont want to break it. Thank youanswer nowA Hi Stephanie, This video on YouTube will help you to solve that - its for a gravity grille but the same principle applies to separate them.https://www.youtube.com/watch?v=UwYjzLIAeNoBut in case you have any problems - you can just slide a screwdriver down the side and pop it off by gently leveraging it from the retaining clips/lugs. I hope that helps to answer your question.RegardsChris
Does the tube protrude so that it has to fit into a wall and, if so, what is the external diameter of the tube?
-
QDoes the tube protrude so that it has to fit into a wall and, if so, what is the external diameter of the tube?answer nowA Hi Paul. The spigot is 150mm, designed to slot inside 150mm PVC Ducting.
Hi
What is the free air rating of this vent please?
-
A Hello Tim, The Free Air for this item is 11440 mm2
Can I get a brown or black grill with an integral insect screen - just had a wasp-nest in our existing shower ducting!
-
QCan I get a brown or black grill with an integral insect screen - just had a wasp-nest in our existing shower ducting!answer nowA Hello NormanThank you for your question we do a round brown grille with fly screen the product code for this item is QS4447. If I can help any further please do not hesitate to contact meKind RegardsAnita
I have a 130mm round flexible aluminium duct coming from a boiler and terminating to an exterior wall. Is this product suitable for that or can you recommend one that is ?
-
QI have a 130mm round flexible aluminium duct coming from a boiler and terminating to an exterior wall. Is this product suitable for that or can you recommend one that is ?answer nowA Hello KevinWe would need to know what is being exhausted from the boiler?Is it gases, water vapour? Are high temperatures involved?
I currently have a Vortice extractor unit fitted to the ceiling above my shower. I want to buy an in-line extractor. Does this spigot fit over the hole where my current extractor is and is it a simple task of connecting this spigot to the in-line extractor via flexible ducting. Thank you
-
QI currently have a Vortice extractor unit fitted to the ceiling above my shower. I want to buy an in-line extractor. Does this spigot fit over the hole where my current extractor is and is it a simple task of connecting this spigot to the in-line extractor via flexible ducting. Thank youanswer nowA Hi AndreIf your existing extractor fan hole is 5 or 125mm then this will be fine.Normally Bathroom extractor fans or 4 or 100mm in size so double check.Relating to installing an in-line fan. In its most basic form you would use a grille on the ceiling like those mentioned above, flexible ducting, quick release worm drive clips and in-line fan and another grille for the outside wall or soffits. If you would like to discuss, please call us on 020 8463 9696.
Does this grill have a fly/spider screen under the louvre?
If not, do any of your grills have a fly/spider screen fitted?
many thanks.
-
QDoes this grill have a fly/spider screen under the louvre? If not, do any of your grills have a fly/spider screen fitted? many thanks.answer nowA Hello Philip Thank you for your question. The product you require is QS38694 we only have a few in stock as it is a discontinued item.
is this product compatible with your 102mm insulated ducting - need it for a bathroom ceiling fan through a cold loft space.
thanks, John
-
Qis this product compatible with your 102mm insulated ducting - need it for a bathroom ceiling fan through a cold loft space. thanks, Johnanswer nowA Hello John Thank you for your question. This grille is normally fitted on the outside with rigid pipe as this is easier to go though the wall. If you require a grille to fit in the ceiling of the bathroom then this item is what is required QS4244.
hi, does the grille have a fine mesh screen behind to stop wasps/flys etc, thanks.
-
A Hello Mike This item doesnt have the fly screen in it but item GALCWL-150 does but it only comes in galvanised steel.
i-sells.co.uk Customer (verified owner) –
Great information and stock M. Wood, Bridgend
Clive Thorne (verified owner) –
Good value – first one slightly damaged, but I-sells replaced quickly and without fuss – excellent service throughout.
Tim Gibbs (verified owner) –
Good quality at price
Barry Clear (verified owner) –
Inexpensive louvred grill. Have used these before. Meets requirements.
David Waters (verified owner) –
good product quite strong
George Tyson (verified owner) –
Easy to fit with enough pipe to fix tube to.
STEPHEN ADAMS (verified owner) –
Sturdy enough looks wise not yet in use until next week bought at the same time as the wall ducting.great service from i.sells.
David Dougherty (verified owner) –
Very good right price
Mark Thomason (verified owner) –
just the job
Alan Marsden (verified owner) –
Requiements fully met
Colin Brotherston (verified owner) –
Very satisfied with this product.
Stewart Rodger (verified owner) –
Does the job stopping possible bird nesting in the outside end and looks neat.
David Rossi (verified owner) –
**************************
Mark Sharland (verified owner) –
good product
Colin Young (verified owner) –
as expected good quality
Sean Keogh (verified owner) –
Was perfect. Was good
Vera Rodan (verified owner) –
Nice and sturdy item. Very good customer service. A lovely lady Annette helped me with the ordering. Item came really quickly. Would definitely recommend.
