Ducting Size Guide
Kair Rotating Elbow Bend Adaptor Rectangular to Round 90 Degree Bend
Found it cheaper? we will match or beat that price for you wherever possible. See Details
You may return an item within 60 days for a full refund. Returns Details | Delivery Details
Rated Excellent by our customers, See Reviews
Need help or have a query? You can fill in our Contact Form or call us on 020 8463 9696
Kair Rotating Rectangular to Round 90 Degree Bend
Plenum bend allows you to run duct inside celling voids or other areas where space is restricted. Rotating spigot allows for easy adjustment.
- Easy to Fit and Durable.
- Made in the UK using high-quality Polystyrene/Polypropylene plastic.
- Max / Min Temperature: +60c / -15c.
Perfectly suited for ducting your Bathroom or Kitchen extractor fan, Hydroponics, In-Line Extract Fans, Tumble Dryer, or Cooker Hood. This bend can be used as a part of a long ductwork run for a variety of purposes including whole house ventilation, passive stack vent, positive input ventilation, air conditioning, HVAC, and Heat Recovery systems.
| Model | DOM941 |
|---|---|
| QS code | QS3070 |
| Barcode | 5014662010463 |
| Product type | Adaptor |
| Product group | Plastic Ducting |
| Flat system (mm) | 220x90 |
| Round system (mm) | 100 |
| Packaged height (mm) | 120 |
| Packaged length (mm) | 245 |
| Packaged width (mm) | 225 |
| Packaged weight (kg) | 0.399 |
| Model | DUCVKC5625 |
|---|---|
| QS code | QS313 |
| Barcode | 5060272542498 |
| Product type | Bend |
| Product group | Plastic Ducting |
| Flat system (mm) | 204x60 |
| Round system (mm) | 100 |
| Width (mm) | 210 |
| Weight (kg) | 0.266 |
| Height (mm) | 86 |
| Length (mm) | 240 |
| Socket size (mm) | 205 |
| Spigot szie (mm) | 100 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polystyrene |
| Pressure loss pa 15 ls | 2.35 |
| Pressure loss pa 30ls | 8.71 |
| Pressure loss pa 60 ls | 32.3 |
| Packaged height (mm) | 64 |
| Packaged length (mm) | 230 |
| Packaged width (mm) | 210 |
| Packaged weight (kg) | 0.266 |
| Model | DUCVKC5606 |
|---|---|
| QS code | QS301 |
| Barcode | 5060272542412 |
| Product type | Bend |
| Product group | Plastic Ducting |
| Flat system (mm) | 204x60 |
| Round system (mm) | 125 |
| Width (mm) | 210 |
| Weight (kg) | 0.26 |
| Height (mm) | 85 |
| Length (mm) | 240 |
| Socket size (mm) | 205 |
| Spigot szie (mm) | 125 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polystyrene |
| Pressure loss pa 15 ls | 1.6 |
| Pressure loss pa 30ls | 6.28 |
| Pressure loss pa 60 ls | 24.69 |
| Packaged height (mm) | 240 |
| Packaged length (mm) | 210 |
| Packaged width (mm) | 65 |
| Packaged weight (kg) | 0.257 |
| Model | DUCVKC5626 |
|---|---|
| QS code | QS315 |
| Barcode | 5060272542504 |
| Product type | Bend |
| Product group | Plastic Ducting |
| Flat system (mm) | 204x60 |
| Round system (mm) | 150 |
| Width (mm) | 210 |
| Weight (kg) | 0.252 |
| Height (mm) | 85 |
| Length (mm) | 240 |
| Socket size (mm) | 205 |
| Spigot szie (mm) | 150 |
| Temp max | 60 |
| Temp min | -15 |
| Material | Polystyrene |
| Pressure loss pa 15 ls | 1.46 |
| Pressure loss pa 30ls | 5.85 |
| Pressure loss pa 60 ls | 23.46 |
| Packaged height (mm) | 64 |
| Packaged length (mm) | 230 |
| Packaged width (mm) | 210 |
| Packaged weight (kg) | 0.247 |
| Model | DOM951 |
|---|---|
| QS code | QS3072 |
| Barcode | 5014662010470 |
| Product type | Adaptor |
| Product group | Plastic Ducting |
| Flat system (mm) | 220x90 |
| Round system (mm) | 125 |
| Width (mm) | NULL |
| Weight (kg) | NULL |
| Height (mm) | NULL |
| Length (mm) | NULL |
| Socket size (mm) | NULL |
| Spigot szie (mm) | NULL |
| SELV | NULL |
| Timer | NULL |
| Pullcord | NULL |
| Humidistat | NULL |
| Maximum suggested long duct run | NULL |
| Power max watts | NULL |
| Power min watts | NULL |
| Thickness | NULL |
| Decibel rating db min | NULL |
| Decibel rating db max | NULL |
| Temp max | NULL |
| Temp min | NULL |
| Free area | NULL |
| Material | NULL |
| Airflow performance ls low | NULL |
| Airflow performance ls med | NULL |
| Airflow performance ls high | NULL |
| Airflow performance mh low | NULL |
| Airflow performance mh med | NULL |
| Airflow performance mh high | NULL |
| Pressure loss pa 15 ls | NULL |
| Pressure loss pa 30ls | NULL |
| Pressure loss pa 60 ls | NULL |
| Pressure loss pa 120 ls | NULL |
| Pressure loss pa 180 ls | NULL |
| Diameter inner mm | NULL |
| Diameter outer mm | NULL |
| Diameter mm | NULL |
| Equivalent area mm | NULL |
| Fan opration modes | NULL |
| Free area cm min | NULL |
| Free area cm max | NULL |
| Packaged height (mm) | 120 |
| Packaged length (mm) | 245 |
| Packaged width (mm) | 225 |
| Packaged weight (kg) | 0.36 |
| Model | DOM961 |
|---|---|
| QS code | QS3076 |
| Barcode | 5014662010487 |
| Product type | Adaptor |
| Product group | Plastic Ducting |
| Flat system (mm) | 220x90 |
| Round system (mm) | 150 |
| Packaged height (mm) | 250 |
| Packaged length (mm) | 230 |
| Packaged width (mm) | 95 |
| Packaged weight (kg) | 0.377 |
| Model | DUCVKC5725 |
|---|---|
| QS code | QS45675 |
| Barcode | 5060272547349 |
| Product type | Adaptor |
| Product group | Plastic Ducting |
| Weight (kg) | 0.373 |
| Packaged height (mm) | 240 |
| Packaged length (mm) | 225 |
| Packaged width (mm) | 120 |
| Packaged weight (kg) | 0.373 |
7 reviews for Kair Rotating Elbow Bend Adaptor Rectangular to Round 90 Degree Bend
You must be logged in to post a review.
Read our full delivery information
Free Delivery Over £100
For items in stock. Excludes timed and non UK Mainland deliveries.
Cut off time 12:00 (noon)
Orders placed after midday will be shipped the following working day.
Free Delivery Over £100
For items in stock. Excludes timed and non UK Mainland deliveries.
Cut off time 12:00 (noon)
Orders placed after midday will be shipped the following working day.
DUCVKC5625 Kair System 204x60mm Rectangular to 100mm Round Rotating Elbow Bend - Technical Data Sheet
DUCVKC5606 Kair System 204x60mm Rectangular to 125mm Round Rotating Elbow Bend - Technical Data Sheet
DUCVKC5606 Kair System 204x60mm Rectangular to 125mm Round Rotating Elbow Bend - Technical Data Sheet
DUCVKC5725 Kair System 220x90mm Rectangular to 100mm Round Rotating Elbow Bend - Technical Data Sheet
Questions and answers of the customers
-
Is the rotating spigot male or female 150mm? Im fitting an Elica BOXIN extractor hood that has a male 150 spigot and only limited space in the wall cabinet.
-
QIs the rotating spigot male or female 150mm? Im fitting an Elica BOXIN extractor hood that has a male 150 spigot and only limited space in the wall cabinet.answer nowA Hello NicThank you for your question. The spigot is male and would require a female sleeve or a piece of pipe to connect together. If I can help any further please do not hesitate to contact meKind RegardsAnita
Is the diameter measurement of 149mm internal or external?
-
A Hello MartinThank you for your question. The 149mm is the internal dimension and the outside dimension is 152mm.Kind RegardsAnita
Good morning,
We have a filtered hob extract system which vents into a narrow (approx 4 inch high) space above kitchen cupboards. We wish to duct the flow through an outside wall, involving a horizontal run of about 8 feet. This fitting appears ok for the point above the hob and also the ducting to the wall.
Do you supply an adaptor to join the ducting to a, through the wall tube ?
Best regards
Roy Bamford
-
QGood morning, We have a filtered hob extract system which vents into a narrow (approx 4 inch high) space above kitchen cupboards. We wish to duct the flow through an outside wall, involving a horizontal run of about 8 feet. This fitting appears ok for the point above the hob and also the ducting to the wall. Do you supply an adaptor to join the ducting to a, through the wall tube ? Best regards Roy Bamfordanswer nowA Hello RoyIf you go to the search bar and type in QS309 you will find a round to rectangular adapter which will convert the straight system 204 to a 125mm round , if you need to go through the wall for any length the round tube will be in the system 125 section umder plastic ducting.I hope this helps.RegardsIan
Is it possible to glue sections of Megaduct 250? If so which product should be used?
-
A Hello PatrickThank you for your question. Yes you can use the pvc pipe cement our product code QS37991 or sealant can also be used. All fittings are male and the pipe is female so will connect together and joints can be sealed with aluminium or duct tape. If i can help any further please do not hesitate to contact me on 0208 463 9683Kind RegardsAnita
what size is the rectangular ducting tube that fits this component?
-
A Hi Patrick Thank you for your question The size of the rectangular ducting is 204mm x 60mm
Rowan Sylvester-Bradley –
Good product, good price, delivered promptly
Gary Bristol (verified owner) –
Purchased ducting to vent a cooker hood my wife wants in the middle of the kitchen. Good product, easy to fit and job done quickly. Excellent service.
simon wright (verified owner) –
used this to make a venting kit for the tumble dryer works well thanks
Thomas Dodds (verified owner) –
Quality product, excellent price and quick delivery.
Carole Williams (verified owner) –
Super product delivered on time
Leslie Davison (verified owner) –
Really handy adjustments helped fit with other ducting. Excellent!
Derek Phillips (verified owner) –
Did the job
